Specially design for Gen. Sets Batteries.
For 4 wheelers battery and 2 wheelers batteries
Specifications:
-High frequency PWM circuit
-Microcontroller based SMPS Battery Charger
-In-Built over voltage protection
-Protection against reverse polarity
-Protection against input surge & inrush current
-Multi-Stage charging reduces over heating
-Compact, light weight, portable & shockproof
-Excellent transient response
-Inbuilt spark free connector
-Protection against short-circuit & overload with pulse-inhibit
-Standard EMI/EMC compliance
-Over temperature shut down
-Force air cooling
For Commercial battery charging uses.
AEI battery chargers are used for charging large battery banks and also provide DC output to the load. Powertek offers DC power systems which use the latest 2 Pulse for single phase & 6 pulse for three phase of SCR type and also IGBT technology offering high input PF and a greater efficiency. Float cum boost chargers ensure that the charger supplies DC load automatically. A float cum boost charger is functionally equipped with two operating modes; a float mode and a boost mode & also current controlled type.
FOR SINGLE PHASE INPUT SYSTEM :
Charger Technology : Thyristor Based, 2 pulse SCR & IGBT Based
Input : 230V AC, Single Phase, 50Hz.
Output : 24V DC-192V DC, 10Amp-100Amp with Boost & Float or Constant current.
Metering : Input voltage, output voltage. Output Current. (Charge/Discharge)
Protection : DC Over, Current limit
Indications : Mains ON, DC ON, DC Over Trip
FOR THREE PHASE INPUT SYSTEM :
Technology : Thyristor Based, 6 pulse SCR & IGBT Based
Input : 415V AC, Three Phase, 50Hz.
Output : 110V DC- 500V DC, 10Amp-150Amp with Float cum Boost or Constant current .
Metering : Input voltage, output voltage. Output Current. (Charge/Discharge)
Protection : DC Over, Current limit
Indications : Mains ON (R,T,B), DC ON, DC Over Trip
Features (Optional) :
Phase fail. Phase reverse protection.
Float/Boost manual setting.
Variable setting of DC charge current.
Main High/Low cut off
